Embolic protectors are used to protect patients from distal embolization during vascular interventions, including peripheral vessels and carotid arteries.
- Thrombus capture is efficient
- Visualization and precise positioning
- The guidewire moves independently of the filter screen, which is safe and stable
|
REF |
Filter size |
Target vessel size (mm) |
Wire length |
Wire diameter |
Conveyor tube sheath OD (mm) |
Recovery tube sheath OD (mm) |
Guide catheter |
|---|---|---|---|---|---|---|---|
|
EPDA-030-190 |
3.0 |
2.0~3.0 |
190 |
0.014" |
1.05 |
1.35 |
1.68/0.066" |
|
EPDA-040-190 |
4.0 |
3.1~4.0 |
|||||
|
EPDA-050-190 |
5.0 |
4.1~5.0 |
|||||
|
EPDA-060-190 |
6.0 |
5.1~6.0 |
|||||
|
EPDA-070-190 |
7.0 |
6.1~7.0 |
|||||
|
EPDB-030-320 |
3.0 |
2.0~3.0 |
320 |
||||
|
EPDB-040-320 |
4.0 |
3.1~4.0 |
|||||
|
EPDB-050-320 |
5.0 |
4.1~5.0 |
|||||
|
EPDB-060-320 |
6.0 |
5.1~6.0 |
|||||
|
EPDB-070-320 |
7.0 |
6.1~7.0 |
